• Native BACnet/IP support

• PWM or 0 to +10V Fan Motor Control

• Control 1 or 2 Fans in Unison

• Monitor RPM & Alarm for Each Fan

• Universal Analog/Binary Input

• Remote LED indicator

• Fan Locate

Power:

• ~24V±20% 50/60Hz, 7VANEC Class 2 USA

• +24V±20%, 5W IEC Class II

Wi-Fi:

• 802.11b/g/n 2.4 GHz

• Static or DCHP IP4 IP Address

• WPA2-PSK Security

• Data Rate = 54 Mbps

• Max Transmit Power = +20 dBmW

• Receiver Sensitivity = -75 dBmW

Motor Control:

• Jumper J5 PWM : +15V, 80Hz PWM, 20mA max.

• Jumper J5 0-10V : 0 to +10V, 20mA max.

• No Jumper : +10V, 80Hz PWM, 20mA max.

• 2 Motors Max.

RPM Signal:

• +5V excitation to Pulsing BJT

  = 0-2000 RPM ±2 RPM

Analog/Binary Input:

• Without Jumper (Analog) : 0 to +10V, ZL=20KΩ

• With Jumper (Binary) : 0 to +20mA, ZL=510Ω

Aux Power:

• +24V, 25mA

Operating Environment:

• 0°F to 130°F / -18°C to 55°C

  Non-Condensing

Connections:

• Power : 0.250" / 6.35 mm Tabs

• Transmitter Input & Power : 3 Pole Screw Terminal

• Motor Connections : 4 Pin MTA-100 Series Connect

Thermal Stability:

• > 0.01%/°F, > 0.018%/°C

BACnet Version:

• Version 1, Revision 19
